Power electronics design
Rectifiers, choppers and inverters: we design the power stage of our equipment, from semiconductor selection to transformer and filter calculation.
Request a quotation
Every CAUM.ELEC unit starts from a design calculation: transformer secondary voltage from the maximum rectified voltage and the semiconductor drops, filter sizing (300 Hz ripple of a three-phase bridge, capacitors and smoothing inductor), rating of thyristors, diodes or IGBTs, temperature rise and cooling.
- Thyristor rectifiers and chargers, single-phase and three-phase bridges
- Choppers and isolating DC/DC converters
- PWM inverters, 50, 60, 200 or 400 Hz output
- IGBT module power stages, SiC transistor gate drivers
- Transformer, smoothing and PFC inductor calculation
- Filtering, protection and heat dissipation
Specifications
- Topologies
- rectifier, chopper, PWM inverter
- Devices
- thyristors, IGBT, SiC
- Magnetics
- transformers, inductors, PFC
- Ratings
- from 600 VA to 160 kVA
Delivered projects
| Project | Specifications | Customer / location |
|---|---|---|
| Thyristor chargers | 48 V – 500 A, 110 V – 190 A | Kuwait |
| On-board inverter | 48 V DC → 115 V 400 Hz, 600 VA | SNCF |
| Locomotive inverters | 72 V DC → 230 V AC, 3,000 VA | Deutsche Bahn |
| Special inverters | 6 kW and 30 kW | Micronics |
How a project runs
- Review of your specification and power budget
- Sizing, wiring diagram and quotation
- Manufacturing and wiring in our Meyzieu workshop
- Load testing before shipment
- Delivery, commissioning and maintenance
Got a project? Send us at least the input and output voltages, the power rating and the required backup time.
